Bottom top right left, Enclosure dimensions – Altronix ALTV615DC Series Installation Instructions User Manual

Page 4

Altronix Corp.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
web site: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
II1ALTV615DCSeries

K20G

MEMBER

Altronix is not responsible for any typographical errors.

5.10"

6.5625"

3.25"

5.10"

3.25"

1.00"

10.50"

1.00"

1.40"

1.20"

1.40"

1.20"

0.75"

11.00"

12.50"

3.25"

0.9375"

1.40"

4.85"

1.40"

1.20"

Bottom

Top

Right

Left

Enclosure Dimensions:

13”H x 13.5”W x 3.25”D

- 4 -

The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated “DANGEROUS VOLTAGE” within the products enclosure that may be of sufficient
magnitude to constitute an electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.

CAUTION: To reduce the risk of electric shock do not open enclosure. There are
no user serviceable parts inside. Refer servicing to qualified service personnel.
