Door
CAUTION: De-energize unit prior to servicing. For continued protection against fire hazard
replace fuse with the same type and rating 3.5A, 250V. Do not expose unit to rain or moisture.
3.5A 250V
For continuous protection against
risk of fire replace fuses with
same type and rating.
common
outputs
protected
outputs
P
N
N
P
S
X
F
M
R
I
n
p
u
t
PD16W
1 23456 78 9 10 11 12 13 14 15 16
N
P
Wire Strap
(from
Enclosure
to Door)
non-
power
limited
XFMR XFMR
Black Lead
White Lead
For models with
factory installed
3-wire line cord
115VAC input
50/60 Hz
Power Supply
Board
Used on PTC Models
(example: ALTV615DC1016CB)
P
N
PTC's
N
P
S
X
F
M
R
I
n
p
u
t
Power Limited Class 2
PD16W
common
outputs
protected
outputs
1 2345678 9 10 11 12 13 14 15 16
P
N
DC outputs
DC outputs
Green
Lead
(ground)
Power
Switch
Terminal Identification:
Power Supply Board
Terminal Legend Function/Description
AC/AC Low voltage AC input.
+ DC -- 6VDC-15VDC output.
PD8UL/PD8ULCB - Distribution Module
1P - 8P Positive DC output.
1N - 8N Negative DC output.
- 3 -
Fig. 1
