1. Mount unit in desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure’s
upper keyholes over the two upper screws, level and secure. Mark the position of the lower two holes. Remove the
enclosure. Drill the lower holes and install the three fasteners. Place the enclosure’s upper keyholes over the two
upper screws. Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pg. 7,8).
Secure enclosure to earth ground.
2. Secure enclosure to earth ground. Connect AC power (115VAC / 60 Hz to terminals marked [L, G, N] (Fig. 1, pg. 3).
Use 14 AWG or larger for all power connections (Battery, DC output, AC input). Use 22 AWG to 18 AWG for power
limited circuits (AC Fail/Low Battery reporting). Keep power limited wiring separate from non-power limited wiring
(115VAC / 60Hz Input, Battery Wires). Minimum .25” spacing must be provided.
3. Measure output voltage before connecting device. This helps avoid potential damage.
When servicing the unit, AC mains should be removed.
4. Connect devices to be powered:
a. For AL1024ULX Power Supply connect devices to terminals marked [- DC +] (Fig. 1, pg. 3)
b. For other Power Distribution Models connect devices to be powered to terminal pairs 1 to 4 marked
[1P & 1N thru 4P & 4N] (Fig. 2A & 2B, pg. 5) or 1 to 8 marked [1P & 1N thru 8P & 8N] (Fig. 3A & 3B, pg. 5)
carefully observing correct polarity.
5. For Access Control applications, batteries are optional. When batteries are not used a loss of AC will result in
the loss of output voltage. When the use of stand-by batteries is desired, they must be lead acid or gel type.
6. Connect appropriate signaling notification devices to terminals marked [AC FAIL & BAT FAIL] (Fig. 1, pg. 3)
supervisory relay outputs.
Note: When used in fire alarm, burglar alarm or access control applications, “AC Fail” relay must be used to
provide a visual indication of AC power on.
7. Please insure that the cover is secured with the provided Key Lock.
LED Diagnostics:
AL1024ULXB - Power Supply Board
Red (DC) Green (AC) Power Supply Status
ON ON Normal operating condition
ON OFF Loss of AC, Stand-by battery supplying power
OFF ON No DC output
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
Terminal Identification:
AL1024ULXB - Power Supply Board
Terminal Legend Function/Description
L, G, N Connect 115VAC to these terminals: L to Hot, N to Neutral, G to ground.
- DC + 24VDC @ 8 amp continuous, 10 amp in alarm non-power limited output, 10 amp continuous when
batteries are not used.
AC FAIL Indicates loss of AC power, e.g. connect to annunciator/alarm panel. Relay normally
NO, C, NC energized when AC power is present. Contact rating 1 amp @ 28VDC.
AC or brownout fail is reported within 0ne (1) minute of event. To delay reporting of up to
6 hrs., cut “AC delay” jumper and reset power to unit.
BAT FAIL Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized
NO, C, NC when DC power is present.
Contact rating 1 amp @ 28VDC.
A removed battery is reported within 1 minute. Battery reconnection is reported
within 1 minute. Low battery threshold: @ approximately 21VDC.
+ BAT - Stand-by battery connections. Maximum charge rate 3.6 amp.
