- 4 -

Fig. 1

ALTV2432 • ALTV2432CB

White

Lead

Power

Switch

Black

Lead

115VAC input,

50/60 Hz.

Used on PTC Models

(example: ALTV2432CB)

Green

Lead

(Ground)

Connected

to Door

3.5A 250V

For continuous protection against risk of fire

replace fuses with same type and rating.

common

outputs

protected

outputs

P

N

N

P

S

X

F

M

R

In

p

u

t

PD16W

1 2345678

9 10 11 12 13 14 15 16

3.5A 250V

For continuous protection against risk of fire

replace fuses with same type and rating.

common

outputs

protected

outputs

P

N

N

P

S

X

F

M

R

In

p

u

t

PD16W

12345678

9 10 11 12 13 14 15 16

P

N

PTC’s

Power Distribution Module

N

P

S

X

F

M

R

In

p

u

t

PD16W

common

outputs

protected

outputs

12345678

9 10 11 12 13 14 15 16

P

N

N

P

P

N

XFMR

XFMR

24VAC or 28VAC

fused or PTC protected outputs

1 through 16.

Input:

24VAC or

28VAC

operation.

Terminal Blocks for Fig. 1
