Overview:
These Altronix CCTV Power Supplies provide 24VAC/28VAC distributed via thirty-two (32) fuse or PTC protected
outputs for powering CCTV Cameras, heaters and other video accessories.
Thirty-two (32) Output ALTV2432 Reference Chart:
ALTV2432
24VAC 8 amp
32 - x 3.5 amp 2.9 amp
28VAC 7 amp
ALTV2432CB
24VAC 8 amp
32 x - 2.5 amp 2.9 amp
28VAC 7 amp
ALTV2432350
24VAC 14 amp
32 - x 3.5 amp 2.7 amp
28VAC 12.5 amp
ALTV2432350CB
24VAC 14 amp
32 x - 2.5 amp 2.7 amp
28VAC 12.5 amp
ALTV2432600
24VAC 28 amp
32 - x 3.5 amp 5.4 amp
28VAC 25 amp
ALTV2432600CB
24VAC 28 amp
32 x - 2.5 amp 5.4 amp
28VAC 25 amp
Specifications:
Installation Instructions:
1. Mount unit in desired location.
2. Turn OFF main switch on unit (Figs. 1-3, pgs. 4-6).
3. All units are factory set for 24VAC operation.
For 28VAC operation, adjust unit prior to mounting and applying power as follows: Change the wire position so that
the black wire [28V] is connected to the terminal marked [P] and the yellow wire [24V] is connected to the
termi nal marked [S].
4. Connect AC power to the black and white flying leads of the transformer(s) (Figs. 1-3, pgs. 4-6), secure green lead to
earth ground. Use 18 AWG or larger for all power connections.
5. Measure output voltage before connecting devices. This helps avoid potential damage.
CAUTION: Determine the maximum operating voltage of the equipment being powered before adjusting
the output voltage.
6. Connect devices to terminals marked [1P - 1N through 16P - 16N] on PD16W/PD16WCB board
(Figs. 1-3, pgs. 4-6), carefully observing polarity. Terminals marked [1P - 16P] are of the same polarity.
- 2 -
Altronix
Model Number
Output Cur
rent
(max per output) Total Output Cur
rent
(P
ow
er)
Output
V
oltage
115V
A
C
50/60Hz Input Cur
rent
Fuse Protected
Outputs Number of Outputs
• Surge suppression.
• AC power LED indicator.
• Power ON/OFF switch / circuit-breaker.
• Unit maintains camera synchronization. • Ease of installation saves time & eliminates costly labor.
• Spare fuses included (on fuse protected models).
Enclosure Dimensions:
13"H x 13.5"W x 3.25"D
PTC Protected Outputs (Class 2 po
w
er limited)
