LED Diagnostics:
Red (DC) Green (AC) Power Supply Statu s
ON ON Normal operating condition
ON OFF Loss of AC, Stand-by battery supplying power
OFF ON No DC output
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output
Terminal Identification:
Terminal Function/Description
Legend
AC / AC Low voltage AC input (28VAC / 200VA).
Two (2) Altronix part # T2885D.
+ DC - 12VDC / 24VDC @ 6 amp continuous non-power limited output.
AC FAIL Used to notify loss of AC power, e.g. connect to audible device or alarm
C, N.C., N.O. panel. Relay normally energized when AC power is present.
Contact rating 1 amp @ 28VDC
Low Battery Used to indicate low battery condition, e.g. connect to alarm panel.
N.O., N.C., C Relay normally energized when DC power is present.
Contact rating 1 amp @ 28VDC
- BAT + Stand-by battery connections. Maximum charge rate .7 amp.
