Altronix VertiLine563 Installation Instructions - Manual (Page 5)

VertiLine563 - 5 -
8.5"
215.90mm
0.75"
19.05mm
19.125"
485.775mm
17.625"
447.675mm
1.625"
41.275mm
8.5"
215.90mm
Rack Mechanical Drawing & Dimensions (HxWxD approx.):
1.625”x 19.125”x 8.5” (41.275mm x 485.775mm x 215.90mm)
Fig. 9
Top
Bottom
