- 8 - eBridge4PCRX
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
IIeBridge4PCRX
G12M MEMBER
A
B
Mounting Hardware (Included):
C
Left Side
Rubber Pad
Six (6) flat head screws
for mounting brackets.
Four (4) rubber pads.
Mounting Options:
Shelf Installation
1- Position and affix rubber pads (C) (included) at each
corner on the bottom of the unit (Fig. 5).
2- Place unit in desired location.
Fig. 5
