- 4 - MOM5 Sub-Assembly
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
MOM5 Sub Assembly - 042811
F16K MEMBER
DOOR STRIKE
(Fail-secure)
MAG LOCK
(Fail-safe)
NC C NO
DRY OUTPUT
TRIGGER
LED 6 7 8 9 10
POS (+) DC OUTPUT (STANDBY)
NC C NO
POWER FAIL
TRIGGER
1 2 3 4 5
POS (+) DC OUTPUT (ALARM)
NEG1 NEG2 NEG3 NEG4 NEG5 -- DC INPUT +
NEG
(-)
INPUT
POS
(+)
FROM FACP
SIGNALING OUTPUT
N.C. TRIGGER
INPUT
EOL 2.2K
FACP
EOL
--
+
TRIGGER
N.O.
TRIGGER
INPUT EOL
2.2K
12 or 24VDC
FROM POWER SUPPLY
Fire Alarm System Power Supply Unit
Also suitable for use as a
Access Control System Unit Subassembly.
9B98
Refer to Installation Instructions
IIMOM5 - REV. 012100
Fig. 7
TRIGGER
LED
POWER
ON LED
TRIGGER
-- INPUT +
NORMALLY OPEN (NO)
INPUT FROM FACP OR
ACCESS CONTROL DEVICE
DC VOLTAGE INPUT FROM
FACP SIGNALING
OUTPUT OR ACCESS
CONTROL DEVICE
(+)
(--)
NC C NO
DRY OUTPUT
NC C NO
POWER FAIL
TRIGGER
LED
POWER
ON LED
TRIGGER
-- INPUT +
NC C NO
DRY OUTPUT
NC C NO
POWER FAIL
EOL 2.2K
EOL
2.2K
NORMALLY
CLOSED (NC)
RESET
Fig. 6 - Two (2) MOM5 modules shown with wet and/or dry normally open fire alarm trigger inputs
(Latching with Manual Reset):
TRIGGER
LED
POWER
ON LED
TRIGGER
-- INPUT +
NORMALLY CLOSED (NC)
INPUT FROM FACP OR
ACCESS CONTROL
DEVICE
DC VOLTAGE INPUT FROM
FACP SIGNALING
OUTPUT OR ACCESS
CONTROL DEVICE
(+)
(--)
NC C NO
DRY OUTPUT
NC C NO
POWER FAIL
TRIGGER
LED
POWER
ON LED
TRIGGER
-- INPUT +
NC C NO
DRY OUTPUT
NC C NO
POWER FAIL
EOL 2.2K EOL 2.2K
NORMALLY OPEN
(NO) RESET
Fig. 5 - Two (2) MOM5 modules shown with wet and/or dry normally closed fire alarm trigger inputs
(Latching with Manual Reset):
