Altronix HubSat 4D Installation Instructions - Manual (Page 7)

HubSat4D - 7 -
Typical Application Drawing for HubSat4D as a Remote Accessory Module
for use with HubWay/HubWayLD/HubWayLDH UTP Transceiver Hubs:
Data
Video
Head End Equipment (DVR)
RS485
Monitor
Rear
Front
1 23 4 CH 1-4 CH 5-8
28VAC
OFF
24VAC
+ DATA -
1-8
5 67 8
PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE AC POWER GAIN
87 6 5 4 3 2 1
Video (Coax)
Power
Video (Coax)
Power
24VAC
Fixed
Camera
Video (Coax)
Power
24VAC/28VAC
Camera Power
Provided
by HubSat4D
115VAC
Input, 50/60Hz
24VAC
Fixed
Camera
Video
Power
HubWayDv
Video Balun
Combiner
CAT-5
CAT-5 CAT-5
12VDC
Fixed
Camera
HubWayAv
Video Balun
Combiner
24VAC
PTZ
Camera
Four (4) Video
signals on a
single CAT-5
Data
(CAT-5)
Four (4) Video
signals on a
single CAT-5
24VAC/28VAC
Camera Power
Provided
by HubSat4D
115VAC
Input, 50/60Hz
HubWayDv
Video Balun
Combiner
Video
Data
Power
Video
Data
Power
12VDC
PTZ
Camera
CAT-5
HubWayAv
Video Balun
Combiner
24VAC
Fixed
Camera
Video
Power
24VAC
Fixed
Camera
Video (Coax)
Power
24VAC
Fixed
Camera
Fig. 6
Fig. 6a - Alternate 24VAC fixed camera hookup.
Typical Application Drawing for
HubSat4D as a Passive UTP Transceiver Hub with Integral Camera Power:
115VAC Input,
50/60Hz
Head End Equipment (DVR)
RS485
BNC
Data
Video
Power
CAT-5
Video
Power
HubWayAv
Video Balun
Combiner
HubWayAv
Video Balun
Combiner
CAT-5
CAT-5
CAT-5
24VAC PTZ
Camera
HubWayDv
Video Balun
Combiner
HubWayDv
Video Balun
Combiner
Video
Data
Power
Video
Data
Power
24VAC/28VAC
Camera Power
Provided
by HubSat4D
24VAC Fixed
Camera
12VDC PTZ
Camera
Monitor
12VDC Fixed
Camera
Fig. 5
