UL Isolated Series - 5 -
Fig. 3 - ALTV2416ULi • ALTV2416ULCBi
115VAC input
50/60 Hz.
Power
Switch
1A
F1 F2 F3 F4 F5 F6 F7 F8
2A 3A 4A 5A 6A 7A 8A
1B 2B 3B 4B 5B 6B 7B 8B
1A
F1 F2 F3 F4 F5 F6 F7 F8
2A 3A 4A 5A 6A 7A 8A
1B 2B 3B 4B 5B 6B 7B 8B
XFMR* XFMR*
1A
F1 F2 F3 F4 F5 F6 F7 F8
2A 3A 4A 5A 6A 7A 8A
1B 2B 3B 4B 5B 6B 7B 8B
Used on PTC Models
(example: ALTV2416ULCBi)
Class 2 power-limited
non power-limited
non power-limited
Green
Lead
(ground)
5A
250V
WARNING: Change fuses with
the same type and rating.
Input: 5 amp @ 250V
Output: 3.5 amp @ 250V
