- 2 - HubWayLD Active Unit
Overview:
Altronix HubWayLD8D/16D Active UTP Transceiver Hub w/Integral Camera Power transmits UTP video, RS422/RS485
data and power over a single CAT-5 or higher structured cable. Unit provides 8 or 16 camera channels in a space saving
1U EIA 19” rack mount chassis which may be rack, wall or shelf mounted. Video transmission range is up to 3000 ft.
max. per channel. Units are compatible with AC and/or DC fixed or PTZ cameras when utilizing Altronix HubWayAv,
HubWayDv or HubWayDvi Video Balun/Combiners. In addition, the unit features individually selectable 24VAC or
28VAC PTC protected outputs with surge suppression. An optional HubSat4D Passive UTP Transceiver Hub with Integral
Camera Power can be used as an accessory module to transmit video from up to 4 cameras over a single CAT-5 or higher
structured cable back to the HubWayLD8D/16D. In addition, the HubSat4D provides power to these cameras locally to
eliminate the possibility of voltage drop associated with long cable runs.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or
moisture. This installation should be made by qualified service personnel and should conform to
all local codes.
Installation Instructions:
1. Set the input voltage selector switch located on the left side of the HubWayLD8D/LD16D unit (facing front panel)
for 115VAC or 230VAC operation (Fig. 1k, pg. 4).
2. Attach mounting brackets to HubWayLD unit for rack or wall mount installation (Figs. 6-7, pg. 8). Affix rubber pads
to HubWayLD for shelf installation (Fig. 8, pg. 8).
HubWayLD Specifications:
Additional Models:
HubWayLD82D
• HubWayLD8D with eight (8) UL Listed Accessory
HubWayAv Video Balun/Combiners for 24VAC Cameras.
HubWayLD83D
• HubWayLD8D with eight (8) UL Listed Accessory
HubWayDv Video Balun/Combiners for 12VDC Cameras.
HubWayLD162D
• HubWayLD16D with sixteen (16) UL Listed Accessory
HubWayAv Video Balun/Combiners for 24VAC Cameras.
HubWayLD163D
• HubWayLD16D with sixteen (16) UL Listed Accessory
HubWayDv Video Balun/Combiners for 12VDC Cameras.
Agency Listings:
• UL Listed for Commercial CCTV
Equipment (UL 2044).
Data:
• RS422/RS485 data inputs.
Power:
• Individually selectable 24VAC or 28VAC power outputs
with OFF position.
• PTC protected outputs.
• PTCs are rated @ 1 amp per channel.
• Surge suppression.
Visual Indicators:
• AC input power indicator.
• Video signal and power LED indicators.
Features:
• Picture and Gain control.
• Illuminated master power disconnect circuit breaker
with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
• Unit can be rack, wall or shelf mounted.
• 1U rack mount chassis for use in standard EIA 19” rack.
Accessories:
• Video Balun/Combiners:
- HubWayAv - for use with 24VAC cameras.
- HubWayDv - for use with 12VDC cameras.
- HubWayDvi - for use with non-isolated 12VDC cameras.
• Optional HubSat4D allows transmission of up to
four (4) video signals over a single CAT-5 or higher
structured cable.
HubWayLD8D/LD82D/LD83D
Input:
• 115VAC 60Hz, 1.5 amp or
230VAC 50/60Hz, 1 amp.
Video:
• Eight (8) channels of video over twisted pair up to
a distance of 3000 ft. per channel.
• Eight (8) 75 ohm video outputs.
Power:
• Unit provides up to 1 amp max. per channel not to
exceed a total of 5 amp (150VA) maximum current.
HubWayLD16D/LD162D/LD163D
Input:
• 115VAC 60Hz, 3 amp or
230VAC 50/60Hz, 1.5 amp.
Video:
• Sixteen (16) channels of video over twisted pair up to
a distance of 3000 ft. per channel.
• Sixteen (16) 75 ohm video outputs.
Power:
• Unit provides up to 1 amp max. per channel not to
exceed a total of 10 amp (300VA) maximum current.
Common Specifications:
