Enclosure Dimensions (H x W x D) (approximate) :
17.5” (444.5mm) x 12” (304.8mm) x 6.625” (168.27mm)
Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com
1.25”
(31.75mm)
9.08”
(230.63mm)
16”
(406.4mm)
12”
(304.8mm)
6.31”
(160.27mm)
1.25”
(31.75mm)
PMK1 Pole Mount Kit (order separately)
PMK1 pole mount kit is designed to simplify installation of outdoor units.
• Accommodates 2”- 8”(diameter) poles.
• Kit includes:
- Two (2) powder coated steel mount brackets.
- Four (4) stainless steel bolts.
- Four (4) stainless steel lock washers.
- Two (2) wormgear quick release straps.
PMK1
