- 6 - HubSat4WP
1 - White/Orange [VIDEO +]
2 - Orange [VIDEO -- ]
3 - White/Green [DATA +]
4 - Blue [AC 1]
5 - White/Blue [AC 2]
6 - Green [DATA -- ]
7 - White/Brown [AC 2]
8 - Brown [AC 1]
Fig. 3 - CAT5 Wiring Color Codes
VIDEO BALUN/COMBINER
CAT5 +DATA-- POWER
AC
VIDEO
HubWayAv
VIDEO
AC Power
to Camera
Data to
Camera --
+ Data to
Camera
Green Power LED
12VDC Power
to Camera +
--
Red Power LED
Wire
Connectors RJ45 Jack RJ45 Jack
To BNC
Connector
of Camera
To BNC
Connector
of Camera
Structured
Cable from
HubSat4WP
Structured
Cable from
HubSat4WP
VIDEO BALUN/COMBINER
HubWayDv
CAT5 +DATA-- -- 12VDC+
--
+
Wire
Connectors
* Also Available as:
HubWayDvi
Video Balun/
Combiner
for non-isolated
12VDC cameras
Fig. 2 - HubWayAv and HubWayDv/Dvi Video Balun/Combiners
Fig. 2c Fig. 2a
Fig. 2b Fig. 2d
HubWayAv passes AC voltage through pins 4, 5, 7, 8 and
[AC Power] terminals. HubWayDv/Dvi converts AC voltage to DC voltage
through pins 4, 5, 7, 8 and [-- 12VDC +] terminals.
White
Lead
Black
Lead
non power-
limited
non power-limited
Green Lead
(Ground)
115VAC
Input
60 Hz.
XFMR
PVD1
VIDEO1 VIDEO2 VIDEO3 VIDEO4
PVD2 PVD3 PVD4
+
D A T A
-
DATA 1-4 VIDEO 1-4
28VAC
24VAC
28VAC
24VAC
28VAC
24VAC
28VAC
24VAC
O F F
O F F
O F F
O F F
AUX1 AUX2
B K
24(YL)
0 (Br)
AUX3 AUX4
Primary
In-line Fuse
(ON)
Fig. 4a
Illuminated master power
disconnect circuit breaker:
• OFF position Circuit breaker
tripped – Switch not
illuminated.
• RESET (ON) position –
Switch illuminated.
Fig. 4
Fig. 4b
Primary In-line fuse:
Rated @ 3.5A/250V
Fig. 4c
