Altronix NetWay112 Installation Instructions - Manual (Page 3)

NetWay112 - 3 -
NVR/Network Server Network Switch
12VDC
input
PoE Camera
CAT-5 additional
100m (328 ft.)
CAT-5
100m (328 ft.)
Port shutdown
input
Netway112
NetwayXT
Video Monitor
Fig. 8
Typical Applications:
Video Monitor NVR/Network Server Network Switch
Netway112
PoE Camera
CAT-5
100m (328 ft.)
Port shutdown
input
12VDC
input
Fig. 5 - Typical Access Control application
NVR/Network Server
NetWay1512
Network Switch
12VDC
IP Camera
CAT-5
100m (328 ft.)
12VDC
input
Port shutdown
input
Video Monitor
Netway112 Fig. 7
PC/Server Network Switch
CAT-5
100m (328 ft.)
UL Listed
Access Control
Power Limited
Power Supply
12VDC
Card
Reader
Electric
Strike
HID
Solo Edge
Device
Netway112
Fig. 6
NetwayXT
Repeater
www.altronix.com
IN OUT Power
Power
LED
Structured
Cable from
NetWay1
Structured
Cable from
PoE Camera/
Device or
next NetWayXT
Port Staus
LEDs
I.T.E. 43KC
Fig. 3 Fig. 4
www.altronix.com
IN OUT
Netway1512
Adapter
12VDC
+ Output ---
+ --
12VDC
Power to
Camera/Device
Structured
Cable from
NetWay1
Structured Cable
from IP Camera/Device
I.T.E.
43KC
