Maximal Rack Access Power Controllers (Fused)

- 3 -

Overview:

These units distribute and switch power to access control systems and accessories. They convert a 115VAC 50/60Hz
input into eight (8) or sixteen (16) independently controlled 12VDC and/or 24VDC fuse protected outputs. Outputs are
activated by an normally open (NO) or normally closed (NC) dry trigger input from an Access Control System, Card
Reader, Keypad, Push Button, PIR, etc. Units will route power to a variety of access control hardware devices includ-
ing: Mag Locks, Electric Strikes, Magnetic Door Holders, etc. Outputs will operate in both Fail-Safe and/or Fail-Secure
modes. The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary
devices. The fire alarm disconnect feature is individually selectable for any or all of the outputs (see chart below).

Maximal Rack Mount Series Configuration Chart:

Altronix

Model Number

Power Supply 1 (8 outputs)

Power Supply 2 (8 outputs)

Total Output Current

Fuse Protected Outputs

Maximum Current Per ACM8R-M Output

115VAC 50/60Hz Input

(current

draw)

Power Supply Board Input Fuse Rating

Maximal1RH

12VDC @ 4 amp

N/A

4 amp

8

2.5

amp

1.9 amp

5A/250V

24VDC @ 3 amp

N/A

3 amp

Maximal1R

12VDC @ 4 amp

N/A

4 amp

16

2.5

amp

1.9 amp

5A/250V

24VDC @ 3 amp

N/A

3 amp

Maximal3RH

12VDC @ 6 amp

N/A

6 amp

8

2.5

amp

1.9 amp

3.5A/250V

24VDC @ 6 amp

N/A

Maximal3R

12VDC @ 6 amp

N/A

6 amp

16

2.5

amp

1.9 amp

3.5A/250Vc

Maximal33R

12VDC @ 6 amp 12VDC @ 6 amp

12 amp

16

2.5

amp

3.8 amp

3.5A/250Vc

24VDC @ 6 amp 24VDC @ 6 amp
12VDC @ 6 amp 24VDC @ 6 amp

Specifications:

Inputs:

• Normally closed [NC] or normally open [NO]
dry contact inputs (switch selectable).

Outputs:

• Individually selectable Mag Lock/Strike (Fail-Safe,
Fail-Secure) solid state fuse protected power outputs.
• Thermal and short circuit protection with auto reset.

Fire Alarm Interface:

• Fire Alarm disconnect (latching with reset or
non-latching) is individually selectable for any or
all of the outputs.
• Remote reset capability for latching Fire Alarm
Interface mode.
• Fire Alarm disconnect input options:
a) Normally open [NO] or normally closed [NC]
dry contact input.
b) Polarity reversal input from FACP signaling circuit.

Visual Indicators:

• Individual Output Status LEDs located on the
front panel.

Battery Backup:

• Built-in charger for sealed lead acid or gel type batteries
(A separate enclosure is required for batteries).
• Maximum charge current .7 amp.
• Automatic switch over to stand-by battery when AC fails.
• Zero voltage drop when unit switches over to battery
backup (AC failure condition).

Supervision:

• AC fail supervision (form “C” contact).
• Low battery supervision (form “C” contact).

Additional Features:

• Removable terminal blocks with locking screw flange.
• 3-wire line cord.
• Illuminated master power disconnect circuit breaker
with manual reset.

Rack Dimensions:

3.25”H x 19.125”W x 8.5”D
