- 8 - HubSat8D
MEMBER
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
IIHubSat8D
E14I
5.10"
6.5625"
3.25" 3.25"
5.10"
5.10"
3.25"
1.00" 10.50" 1.00"
1.00" 1.00"
1.40"
1.20"
1.40"
1.20"
0.75" 0.75" 11.00"
12.50"
3.25"
0.9375"
0.9375"
1.40" 4.85" 4.85" 1.40"
1.20"
Bottom
Top
Right Left
Enclosure Dimensions:
13.5”H x 13”W x 3.25”D
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated “DANGEROUS VOLTAGE” within the products enclosure that may be of sufficient
magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
CAUTION: To reduce the risk of electric shock do not open enclosure. There
are no user serviceable parts inside. Refer servicing to qualified service personnel.
