- 2 - eFlow102N Series
Overview:
The eFlow102N power supply/chargers convert a 120VAC / 60Hz input to a 12VDC nominal output
(see Power Supply Configuration Reference Chart and Specifications).
eFlow102N Series Power Supply Configuration Reference Chart:
Altronix Model Number
Nominal DC Outputs
Maximum Supply Current for Main and Aux. Outputs(amp) Input Rating: 120VAC, 60Hz Input Fuse Rating Battery Fuse Rating Ripple Voltage (mV) Under low battery condition Power Distribution Modiule Number of Outputs Fused Outputs Ratings PTC Outputs Ratings Accommodates up to 7AH Batteries Accommodates up to 12AH Batteries
[DC] [AUX]
12VDC Output Range (volts) 12VDC Output Range (volts)
eFlow102N
10.03-13.2 10.03-13.2 10A 3.5A 5A/250V 15A/32V 760 N/A 1
– – 3 –
eFlow102NX – – – 3
eFlow102N8
10.03-13.2 10.03-13.2 10A 3.5A 5A/250V 15A/32V 760 PD8UL 8
2.5A – 3 –
eFlow102NX8 2.5A – – 3
eFlow102N8D
9.78-13.2 10.03-13.2 10A 3.5A 5A/250V 15A/32V 760 PD8ULCB 8
– 2A 3 –
eFlow102NX8D – 2A – 3
eFlow102N16
10.03-13.2 10.03-13.2 10A 3.5A 5A/250V 15A/32V 760
PD16W
16
2.5A – 3 –
eFlow102NX16 2 - PD8UL 2.5A – – 3
eFlow102N16D
9.78-13.2 10.03-13.2 10A 3.5A 5A/250V 15A/32V 760
PD16WCB
16
– 2A 3 –
eFlow102NX16D 2 - PD8ULCB – 2A – 3
These units provide non power-limited outputs: eFlow102N, eFlow102NX, eFlow102N8, eFlow102NX8, eFlow102N16 and
eFlow102NX16. These units provide power-limited outputs: eFlow102N8D, eFlow102NX8D, eFlow102N16D and eFlow102NX16D.
If a power-limited output is required in the end-product application, the DC output from the power supply must be connected to a
separately Listed control unit or accessory board that provides power-limited outputs. The product(s) providing the power-limited
output(s) must be listed as appropriate for the particular end-product application (fire alarm, burglar alarm, access control), and wired
in accordance with the products installation instructions. Class 1 wiring methods, separation of circuits, and proper fire-rated enclo-
sures all must be considered when connecting the DC output of the power supply to the end-product devices. The auxiliary output of
these units are power-limited.
UL Listings for US Installations:
UL 294 - UL Listed for Access Control System Units.
UL 603 - UL Listed for Power Supplies for Use with Burglar-Alarms Systems.
UL 1481 - UL Listed for Power Supplies for Fire Protective Signaling Systems.
UL Listings for Canadian Installations:
ULC-S318-96 - Power Supplies for Burglar Alarm Systems. Also suitable for Access Control.
California State Fire Marshal
(eFlow102N and eFlow102NX only)
CE Approved
Stand-by Specifications:
Battery
Burg. Applications
4 hr. Stand-by/
15 min. Alarm
Fire Applications
24 hr. Stand-by/
5 min. Alarm
Access Control
Applications
Stand-by
7AH 0.4 amp/10 amp N/A 5 Mins./10 amp
12AH 1 amp/10 amp 0.3 amp/10 amp 15 Mins./10 amp
40AH (for eFlow102NX refer to Fig. 8, pg. 10) 6 amp/10 amp 1.2 amp/10 amp Over 2 Hours/10 amp
65AH (for eFlow102NX refer to Fig. 8, pg. 10) 6 amp/10 amp 1.5 amp/10 amp Over 4 Hours/10 amp
