60
10 Supplement
VEGABAR 87 • Modbus and Levelmaster protocol
46297-EN-131107
Interface to the slave sensor
Data transmission
digital (I²C-Bus)
Configuration, connection cable 4-wire, screened
Cable length max. 25 m
Integrated clock
Date format
Day.Month.Year
Time format 12 h/24 h
Time zone Ex factory CET
Rate deviation max. 10.5 min/year
Measurement electronics temerature
Resolution
1 °C (1.8 °F)
Accuracy ±1 °C (1.8 °F)
Voltage supply
Operating voltage
8 … 30 V DC
Power consumption < 500 mW
Interpolation protection Integrated
Potential connections in the instrument
Electronics
Not non-floating
Ground terminal Galvanically connected with the process fitting
Electrical protective measures
Housing material Version IP-protection class NEMA protection
Plastic Single chamber IP 66/IP 67 NEMA 4X/6P
Double chamber IP 66/IP 67 NEMA 4X
Aluminium Single chamber IP 66/IP 68 (0.2 bar)
IP 68 (1 bar) NEMA 4X/6P
-
Double chamber IP 66/IP 67
IP 66/IP 68 (0.2 bar) NEMA 4X
NEMA 4X
Stainless steel, electro-
polished
Single chamber
Single chamber IP 69K
IP 66/IP 68 (0.2 bar) -
NEMA 4X/6P
Stainless steel, investment
casting
Single chamber IP 66/IP 68 (0.2 bar)
IP 68 (1 bar) NEMA 4X/6P
NEMA 4X
Double chamber IP 66/IP 67
IP 66/IP 68 (0.2 bar) NEMA 4X
NEMA 4X
Stainless steel Transmitter for external
housing
IP 68 (25 bar) -
Overvoltage category III
Protection class II
