11 Supplement
MINITRAC 31 • Foundation Fieldbus
41782-EN-131119
Channel Numbers
Ʋ Channel 1 Process value (level)
Ʋ Channel 8 Electronics temperature
Ʋ Channel 9 Pulse rate
Transmission rate 31.25 Kbit/s
Current value 10 mA, ±0.5 mA
Resolution, digital > 0.1 mm (0.004 in)
Output variable - Density measurement
Output
Ʋ Signal digital output signal, Foundation Fieldbus protocol
Ʋ Physical layer according to IEC 61158-2
Damping (63 % of the input variable) 0 … 999 s, adjustable
Channel Numbers
Ʋ Channel 1 Process value (density)
Ʋ Channel 3 Process temperature (with external temperature sensor)
Ʋ Channel 8 Electronics temperature
Ʋ Channel 9 Pulse rate
Transmission rate 31.25 Kbit/s
Current value 10 mA, ±0.5 mA
Resolution, digital > 0.1 mm (0.004 in)
Output variable - Level detection
Output
Ʋ Signal digital output signal, Foundation Fieldbus protocol
Ʋ Physical layer according to IEC 61158-2
Damping (63 % of the input variable) 0 … 999 s, adjustable
Channel Numbers
Ʋ Channel 1 Process value (switching status)
Ʋ Channel 8 Electronics temperature
Ʋ Channel 9 Pulse rate
Transmission rate 31.25 Kbit/s
Current value 10 mA, ±0.5 mA
Resolution, digital > 0.1 mm (0.004 in)
Output variable - X-ray alarm
Output
Ʋ Signal digital output signal, Foundation Fieldbus protocol
Ʋ Physical layer according to IEC 61158-2
Damping (63 % of the input variable) 0 … 999 s, adjustable
Channel Numbers
Ʋ Channel 1 Process value
