34
6 Set up with the display and adjustment module
MINITRAC 31 • Foundation Fieldbus
41782-EN-131119
Menu Menu item Default value
Setup Measurement loop name Sensor
Isotope Cs-137
Application Level
Background radiation 0 ct/s
Unit of the process value %
Temperature unit ° C
Adjustment min. Min. process value = 0 %
Adjustment max. Max. process value = 100 %
Linearization 0 ct/s = 100 %
90000 ct/s = 0 %
Damping 60 s
Real value correction 0
Mode Overfill protection
Upper switching point - Pro-
cess value
0 %
Lower switching point - Pro-
cess value
0 %
Upper switching point - Tem-
perature
50 °C
Upper switching point - Tem-
perature
25 °C
Reference value - Relay None
Block adjustment Released
Address - Summation Slave free
Display Language Selected language
Displayed value Pulse rate
Display unit ct/s
Additional ad-
justments
Temperature unit °C
Linearisation curve Empty
HART mode Standard
Address 0
6.4 Parameter adjustment - Density
measurement
The instrument is adapted to the application conditions via the pa-
rameter adjustment. The parameter adjustment is carried out with an
adjustment menu.
Information:
In this operating instructions manual, the instrument-specific param-
eters are described. Further general parameters are described in the
operating instructions manual "Display and adjustment module".
