11 Supplement
VEGAFLEX 81 • HART - integrated accumulator
44640-EN-130430
Display and adjustment module
Display element
Display with backlight
Measured value indication
Ʋ Number of digits 5
Ʋ Size of digits W x H = 7 x 13 mm
Adjustment elements 4 keys
Protection rating
Ʋ unassembled IP 20
Ʋ mounted into the housing without
cover
IP 40
Material
Ʋ Housing ABS
Ʋ Inspection window Polyester foil
Display and adjustment elements
Display elements
Ʋ Green LED in the supply room Indication of the charging process
Ʋ Yellow LED in the supply room Indication of the charging condition
Adjustment elements
Ʋ Rotary switch in the supply room Selection of the mode
Ʋ Button outside on the housing Switching on and off
Integrated clock
Date format
Day.Month.Year
Time format 12 h/24 h
Time zone Ex factory CET
Measurement electronics temerature
Resolution
1 °C (1.8 °F)
Accuracy ±1 °C (1.8 °F)
External battery charger
Mains voltage
100 … 240 V AC
Output voltage 24 V DC
Output current (shortcircuit proof) max. 500 mA
Load current limitation
70 mA
DC plug (inside plus, outside minus) 2.1 mm
Integrated accumulator
Type
Lithium ions
Voltage 14.8 V
Accumulator capacity 4.7 Wh
Charging period from 0 % to 100 %
approx.
4 h
