Electromechanical data - version IP 66/IP 68, 1 bar
C
able entry
-
S
ingle chamber housing
l
1
x IP 68 cable gland M20 x 1.5; 1 x blind
stopper M20 x 1.5
or:
l
1
x closing cap ½ NPT, 1 x blind plug ½ NPT
-
D
ouble chamber housing
l
1
x IP 68 cable gland M20 x 1.5; 1 x blind
stopper M20 x 1.5; plug M12 x 1 for VEGADIS
61 (
optional)
or:
l
1
x closing cap ½ NPT, 1 x blind stopper
½ NPT,
plug M12 x 1 for VEGADIS 61
(
optional)
C
onnection cable
-
C
onfiguration
four wires, one suspension cable, one breather
capillary, screen braiding, metal foil, mantle
-
W
ire cross-section
0.5
mm² (AWG 20)
-
W
ire resistance
<
0.036 Ω/
m (0.011 Ω/ft)
-
T
ensile strength
>
1200 N (270
pounds force)
-
S
tandard length
5
m (16.4 ft)
-
M
ax. length
1000
m (3281 ft)
-
M
in. bending radius at 25 °C/77 °F
25
mm (0.985 in)
-
D
iameter approx.
8
mm (0.315 in)
-
C
olour - standard PE
B
lack
-
C
olour - standard PUR
B
lue
-
C
olour - Ex-version
B
lue
Indicating and adjustment module
V
oltage supply and data transmission
through the sensor
I
ndication
LC
display in dot matrix
A
djustment elements
4
keys
P
rotection
-
unassembled
IP
20
-
mounted into the sensor without cover
IP
40
M
aterials
-
H
ousing
ABS
-
I
nspection window
P
olyester foil
