4.2 Mounting instructions
VEGABAR 52 functions in any installation position. It is mounted
according to the same directives as a manometer (DIN EN 839-2).
Information:
W
e recommend using lock fittings, measuring instrument holders and
siphons from our line of accessories.
4.3 Mounting steps
F or mounting VEGABAR 52, a welded socket is required. You can find
these components in the supplementary instructions manual "Welded
socket and seals".
U se the seal corresponding to the instrument:
l P rocess fitting GV, GB, GC, GI: Tesnit seal in front of the thread
l P rocess fitting GP, GL, GS: Klingersil seal behind the thread
- or -
S eal the thread with teflon, hemp or a similar resistant seal material:
l P rocess fitting GN
à Screw VEGABAR 52 into the welded socket. Tighten the hexagon
on the process fitting with a suitable wrench. Wrench size, see
chapter "Dimensions".
Warning:
T
he housing must not be used to screw the instrument in! Applying
tightening force can damage internal parts of the housing.
Mounting position
Welding the socket
Sealing/Screwing in
