5 C onfirm with [+] and move to max. adjustment with [->].
T
he min. adjustment is finished.
Information:
F
or an adjustment with filling, you simply enter the displayed actual
measured value. If the adjustment ranges are exceeded, the message
"Outside parameter limits" appears. The editing procedure can be
aborted with [ESC] or the displayed limit value can be accepted with
[OK]
.
P roceed as follows:
1 E dit the % value in the menu item "Max. adjustment" with [OK].
M ax. adjustment
+100 .0 %
=
+1000 .0 mbar
0000.0 mbar
Information:
T
he displayed pressure for 100 % corresponds to the nominal
measuring range of the sensor (in the above example 1 bar =
1000
mbar).
2 S et the requested percentage value with [->] and [OK].
3 E
dit the requested mbar value with [OK].
4 S et the requested mbar value with [+] and [->].
5 C onfirm with [OK] and move to the menu overview with [ESC].
T he max. adjustment is finished.
Information:
F
or an adjustment with filling, you simply enter the displayed actual
measured value. If the adjustment ranges are exceeded, the message
"Outside parameter limits" appears. The editing procedure can be
aborted with [ESC] or the displayed limit value can be accepted with
[OK]
.
Process pressure measurement
S et up VEGABAR 52 in the following sequence:
1 S elect application "Process pressure measurement"
2 S elect the unit of measurement
3 C arry out position correction
4 C arrying out zero adjustment
5 C arrying out span adjustment
I
n the menu item "Adjustment unit" you select the physical unit in which
the adjustment should be carried out, e.g. mbar, bar, psi…
Carrying out max. ad-
justment
Parameter ad-
justment "Proc-
ess pressure
measurement"
