Offline mode
The project can be prepared, created and stored in offline
mode without instruments being connected. Later these data
can be transferred in online mode to the instruments now being
ready for operation. Keep in mind that saving of these data on
the hard drive is only possible in the Professional version with
costs.
Online mode
In online mode, the instruments on which the parameter
adjustment is to be carried out must be connected and ready
for operation. By selecting the appropriate DTM with the right
mouse key and the command "Connect", the online mode is
set up for operation. After double clicking, connection is
initiated which simultaneously checks the communication, the
sensor type and additional parameters. If necessary, all
parameters will be transferred automatically. Via the DTM
menu item "Device data - Read data from device", all
parameters of the sensor can be loaded anytime. All settings
which are carried out now must be transferred afterwards to
the instrument. This can be done via the DTM menu item
"Device data - Write data to device".
Fig. 9: DTM connection to VEGALOG 571
The most important thing is to creare the requested
measurement loops. For this purpose, a comfortable assistant
is available which is asking for the necessary settings. Select
the DTM menu item "Measurement loops" and push the button
"Create new measurement loop". The following applications
are available:
l
Level measurement
l
Process pressure measurement
Create measurement loops
