Coupling of the carriers
If the number of the available modules of a carrier (BGT) is not
sufficient, the VEGALOG 571 can be also completed with a
second BGT.
The carriers are place above another and connected via the
supplied ribbon cable. On the rear of the bus board there is an
appropriate plug connection.
For the configuration with two carriers you have to set the
following two switch positions according to below description.
l
Hook switch for the termination resistor
l
Slide switch
Hook switch - closed
Slide switch - position M
l
BGT 1
- Hook switch - closed
-
Slide switch - position M
l
BGT 2
- Hook switch - open
-
Slide switch - position S
Switch position, one BGT
Switch position, two BGT
