from the instrument catalogue to the project window with a
double click or Drag and Drop. If the project window or the
instrument catalogue are not visible, they can be activated in
the menu bar under " View ".
6.6 Example projects
Project creation VEGALOG and Profibus PA sensor
The following example shows a typical VEGALOG project with
EP card and Profibus sensors. We recommend using the
"VEGA project assistant", this considerably facilitates the
project creation and errors during the address assignment of
the VEGALOG module cards and the sensors are avoided. All
existing cards are found automatically and are added to the
project. Also all connected Profibus sensors are automatically
taken over into the project.
In case the planning is nevertheless carried out manually, e.g.
when creating an offline project, the following DTMs must be
added to the project tree:
1 First of all a driver must be selected by which the
communication via the PC can be carried out. Select the
"VEGA Ethernet" DTM from the instrument catalogue. With
this driver, the connection to VEGACOM 558 in the
VEGALOG 571 processing system is established.
When the "VEGA Ethernet" DTM in the project tree is
selected, you can later adjust the IP address for the
VEGACOM 558 module card in the PACTware™ menu
under "Device data - Add'l functions - Change DTM
addresses". The implementation of this setting is only
possible if a suitable DTM (e.g. VEGACOM 558) has
already been added to the project tree.
2 Finally the DTM "VEGALOG 571" must be added. This
DTM represents the VEGALOG 571 processing system. In
this DTM, measurement loops are created and processed
later on.
When the "VEGALOG 571" DTM in the project tree is
selected, you can later adjust the card addresses for the
VEGALOG module cards in the PACTware™ menu under
"Device data - Add'l functions - Change DTM addresses".
The implementation of this setting is only possible if a
corresponding DTM (e.g. VEGACOM 558) has already
been added to the project tree.
Connection via VE-
GACOM 558/Ethernet
