10 Supplement
PLICSRADIO T62 • Wireless emitting unit (multiple channel)
32624-EN-130228
10 Supplement
10.1 Technical data
General data
316L corresponds to 1.4404 or 1.4435, 316Ti corresponds to 1.4571
Materials
Ʋ Housing plastic PBT, Alu die-casting, 316L
Ʋ Inspection window in housing cover
for display and adjustment module
Polycarbonate (UL-746-C listed)
Ʋ Ground terminal 316Ti/316L
Weight
Ʋ Plastic housing 840 g (1.851 lbs)
Ʋ Aluminium housing 1300 g (2.866 lbs)
Voltage supply
Operating voltage depending on the version of the power supply unit
Ʋ 24 V version 9.6 … 48 V DC, 24 … 42 V AC
Ʋ 115/230 V version 90 … 253 V AC, 50/60 Hz
Max. power consumption depending on the type of power supply unit
Ʋ 24 V version 5.3 VA; 3.5 W
Ʋ 115/230 V version 5 VA; 2.4 W
HART sensor input
Number of sensors
3 x 4 … 20 mA/HART (2 x when using the 4 … 20 mA
input)
Type of input (selectable)
Ʋ Active input Sensor is powered by PLICSRADIO T62
Ʋ Passive input Sensor has an own voltage supply
Measured value transmission
Ʋ digital HART protocol
Terminal voltage 18 … 14.5 V at 4 … 20 mA
Current limitation 25 mA
Connection cable to the sensor two-wire screened standard cable
4 … 20 mA sensor input
Number of sensors
1 x 4 … 20 mA
Type of input (selectable)
Ʋ Active input Sensor is powered by PLICSRADIO T62
Ʋ Passive input Sensor has an own voltage supply
Measured value transmission
Ʋ 4 … 20 mA analogue for individual 4 … 20 mA sensors
Terminal voltage 18 … 14.5 V at 4 … 20 mA
Current limitation 25 mA
