4
1 Function as Modbus-TCP server
Modbus-TCP, ASCII protocol • VEGAMET 391/624/625, VEGASCAN 693, PLICSRADIO C62
30768-EN-130701
Register address in
Modicon
Temporary memory of VEGAMET/PLICSRADIO
(1 word = 2 byte)
30004 PC/DCS output 2: Status
30005 PC/DCS output 3: Measured value
30006 PC/DCS output 3: Status
30007 PC/DCS output 4: Measured value
30008 PC/DCS output 4: Status
30009 PC/DCS output 5: Measured value
30010 PC/DCS output 5: Status
30011 PC/DCS output 6: Measured value
30012 PC/DCS output 6: Status
Register address in
Modicon
Temporary memory of VEGASCAN (1 word =
2 byte)
30001 PC/DCS output 1: Measured value
30002 PC/DCS output 1: Status
30003 PC/DCS output 2: Measured value
30004 PC/DCS output 2: Status
30005 PC/DCS output 3: Measured value
30006 PC/DCS output 3: Status
30007 PC/DCS output 4: Measured value
30008 PC/DCS output 4: Status
30009 PC/DCS output 5: Measured value
30010 PC/DCS output 5: Status
30011 PC/DCS output 6: Measured value
30012 PC/DCS output 6: Status
… …
30057 PC/DCS output 29: Measured value
30058 PC/DCS output 29: Status
30059 PC/DCS output 30: Measured value
30060 PC/DCS output 30: Status
As an alternative, register address 40001 is also available as start
address (function code 03).
The actual measured values are transmitted as signed data compris-
ing two octets. This means that the value range encompasses max.
+32768 to -32767. In addition to the measured value, the status of the
measured value is delivered in a second register word.
Format of the PC/DCS
value
