Connection cable
-
Wire cross-section 0.5 mm² (AWG 20)
-
Wire resistance < 0 .036 Ω/m (0.011 Ω/ft)
-
Tensile strength < 1200 N (270 lbf)
-
Standard length 5 m (16.4 ft)
-
Max. length 1000 m (3280 ft)
-
Min. bending radius 25 mm (0.984 in) with 25 °C (77 °F)
-
Diameter approx. 8 mm (0.315 in)
-
Colour - standard PE Black
-
Colour - standard PUR Blue
-
Colour - Ex-version Blue
Indicating and adjustment module
Voltage supply and data transmission through the sensor
Indication LC display in dot matrix
Adjustment elements 4 keys
Protection rating
-
unassembled IP 20
-
mounted into the sensor without cover IP 40
Materials
-
Housing ABS
-
Inspection window Polyester foil
Voltage supply
Operating voltage
-
Non-Ex instrument 9 … 32 V DC
-
EEx-ia instrument 9 … 24 V DC
-
EEx-d instrument 16 … 32 V DC
Operating voltage with illuminated indicating and adjustment module
-
Non-Ex instrument 12 … 32 V DC
-
EEx-ia instrument 12 … 24 V DC
-
EEx-d instrument 20 … 32 V DC
Power supply by/max. number of sensors
-
H 1 power supply max. 32 (max. 10 with Ex)
Electrical protective measures
Protection, depending on housing version
-
Plastic housing IP 66/IP 67
