10 Annex
10 .1 Technical data
General data
Materials, wetted parts
-
Process fitting 316L
-
Antenna encapsulated or hygienically
encapsulated PTFE (TFM 1600), PFA plated, PVDF
-
Process seal with hygienically encapsu-
lated antenna FKM (Viton), EPDM
Materials, non-wetted parts
-
Housing Plastic PBT (polyester), Alu die-casting powder-
coated, 316L
-
Seal between housing and housing
cover NBR (stainless steel housing), silicone (Alu/plastic
housing)
-
Inspection window in housing cover for
PLICSCOM Polycarbonate (UL-746-C listed)
-
Ground terminal 316Ti/316L
Torque of the flange screws (min.) 60 Nm (44.25 lbf ft)
Weight
-
Clamp, bolting, depending on size and
housing material 3.5 … 6.0 kg (7.716 … 13.22 lbs)
-
Flanges, depending on flange size and
housing material 4.2 … 15.4 kg (9.259 … 33.95 lbs)
Output variable
Output
-
Signal digital output signal, Foundation Fieldbus protocol
-
Physical layer according to IEC 61158-2
Cycle time min. 1 s (dependent on the parameter setting)
-
Damping (63 % of the input variable) 0 … 999 s, adjustable
-
Fulfilled NAMUR recommendations NE 43
Channel Numbers
-
Channel 1 Primary value
-
Channel 2 Secondary value 1
-
Channel 3 Secondary value 2
Transmission rate 31.25 Kbit/s
Current value 10 mA, ±0.5 mA
Resolution, digital > 1 mm (0.039 in)
