44
10 Supplement
VEGASON 61 • Foundation Fieldbus
28790-EN-130417
Display and adjustment module
Voltage supply and data transmission
through the sensor
Indication LC display in dot matrix
Adjustment elements 4 keys
Protection rating
Ʋ unassembled IP 20
Ʋ mounted into the sensor without cover IP 40
Material
Ʋ Housing ABS
Ʋ Inspection window Polyester foil
Voltage supply
Operating voltage
Ʋ Non-Ex instrument 9 … 32 V DC
Ʋ Ex-ia instrument 9 … 24 V DC
Ʋ Exd instrument 16 … 32 V DC
Operating voltage with illuminated display and adjustment module
Ʋ Non-Ex instrument 12 … 32 V DC
Ʋ Ex-ia instrument 12 … 24 V DC
Ʋ Exd instrument 20 … 32 V DC
Power supply by/max. number of sensors
Ʋ Fieldbus max. 32 (max. 10 with Ex)
Electrical protective measures
Protection, depending on housing version
Ʋ Plastic housing IP 66/IP 67
Ʋ Aluminium housing, stainless steel
housing - investment casting, stain-
less steel housing - electro-polished
IP 66/IP 68 (0.2 bar) 11)
Ʋ Aluminium and stainless housing, in-
vestment casting (optionally available)
IP 66/IP 68 (1 bar)
Overvoltage category III
Protection class II
Approvals
Instruments with approvals can have different technical data depending on the version.
For that reason the associated approval documents of these instruments have to be carefully
noted. They are part of the delivery or can be downloaded under www.vega.com via "VEGA Tools"
and "serial number search" as well as via "Downloads" and "Approvals".
11) A suitable cable is the prerequisite for maintaining the protection rating.
