10 VEGALOG 571
Product description
1.4 Technical data
Common data (except VEGASTAB 593)
Power supply
Operating voltage of the cards U
nom
= 24 V DC (18 … 36␣ V)
Power consumption
- CPU-card
max. 6 W
- EA-card max. 11 W
- EV-card max. 10 W
- AA-card max. 9 W
- AD-card max. 10 W
- AR-card max. 6 W
- AT-card max. 6 W
- VEGACOM 557 max. 6 W
Fuse 1 A slow-blow
Electrical connection
Module card multiple plug acc. to DIN 41 612, series F,
48-pole (d, b, z) with coding hole
Module in carrier BGT LOG 571 suitable multipoint connector acc. to DIN 41 612
with connection via standard technologies
Electrical protective measures
Protection
not mounted
IP 00
in carrier BGT LOG 571
- front side completely equipped
IP 40
- upper and lower side IP 20
- wiring side IP 00
Protection class I (in carrier BGT LOG 571)
Overvoltage category II
CE-conformity
The module cards of VEGALOG 571 meet the protective regulations of EMVG
(89/336/EWG) and NSR (73/23/EWG). The conformity has been judged acc. to the following
standards:
EMVG Emission
EN 50 081 - 2
Susceptibility EN 50 082 - 1
NSR EN 61 010
Ambient conditions
Permissible ambient temperature -20
°
C … +60
°
C
Storage and transport temperature -20
°
C … +80
°
C
Mechanical data
Series module cards for carrier
BGT LOG 571
Dimensions, not mounted W = 25,4 mm (5 TE), H = 128,4 mm (3 HE),
D = 166 mm
Weight per card approx. 400 g
