VEGA Conductive electrodes - Manual (Page 11)

Conductive measuring system 11
Product description
Electrical protective measures
Protection
- not mounted
IP 00
- mounted into
carrier BGT 596 Ex front side completely equipped IP 30
upper and lower side IP 20
wiring side IP 00
- mounted into
housing type 505 Ex IP 30
Protection class II
Overvoltage category II
Electrical connection
Mounted into
- carrier BGT 596 Ex
33-pole multipoint connector, series F (d, b, z)
with coding holes
- housing type 505 Ex screw terminal, max. for 1,5 mm 2
CE-conformity
VEGATOR 532 Ex signal conditioning instrument meets the protective regulations of EMVG
(89/336/EWG) and NSR (72/23/EWG). The conformity has been judged acc. to the following
standards:
EMVG Emission
EN 50 081 - 1
Susceptibility EN 50 082 - 2
NSR EN 61 010 - 1
Signal conditioning instrument VEGATOR 631 Ex
General
Series module unit with plug-in socket including
transparent cover, cover of the probe
terminals,
coded pin, 2 bridges
Dimensions W = 36 mm, H = 118,5 mm, D = 134 mm
Weight approx. 170 g
Mounting carrier rail mounting acc. to DIN 46 277, Bl 3
Power supply
Operating voltage 20 … 250 V AC, 50/60 Hz
20 … 72 V DC
Power consumption max. 1,5 W, approx. 1 … 9 VA
Fuse
- supply range
T 315 mA, 250 V
- switching power min. 35 A at 250 V AC or 125 V DC
