Page 99
197
www.wiha.com
196
7050
5/16" impact screwdriver bits, slotted.
Material:
High-quality chrome-molybdenum steel, through-hardened,
phosphate coated surface.
Drive:
DIN 3126, ISO 1173, style C 8.
Application:
For slotted screws for use in impact screwdrivers.
Extra:
Especially impact-resistant.
7051
5/16" impact screwdriver bits, Phillips.
Material:
High-quality chrome-molybdenum steel, through-hardened,
phosphate coated surface.
Drive:
DIN 3126, ISO 1173, style C 8.
Application:
For Phillips screws for use in impact screwdrivers.
Extra:
Especially impact-resistant.
7055
5/16" impact screwdriver bits, TORX
®
.
Material:
High-quality chrome-molybdenum steel, through-hardened,
phosphate coated surface.
Drive:
DIN 3126, ISO 1173, style C 8.
Application:
For TORX
®
screws for use in impact screwdrivers.
Extra:
Especially impact-resistant.
24636
1/2" hand impact screwdriver.
Material:
High-quality chrome-molybdenum steel, through-hardened,
with hand protection.
Drive:
Square 1/2".
Application:
For loosening jammed screws or nuts together
with the Wiha 5/16" impact bits and holder.
Maximum transmissible torque of up to 200 Nm.
Extra:
The insert is hardened and lacquered at the impact end to prevent the
chipping of chrome parts or mushroom-shaped deformations.
Note:
Can only be used with adapter 72040 (5/16" to 1/2")
7204Z-516
Power bit holder.
Material:
High-quality chrome-molybdenum steel, through-hardened,
chrome-plated and polished.
Drive:
DIN 3120.
Application:
For use of C 8 bits.
Required for use with hand impact screwdriver, series 24636.
7210
Tool shaft, style C 6.3.
Suitable for:
DIN 3120, ISO 1174, style A 6.3 + A 10.
Drive:
DIN 3126, ISO 1173, style C 6.3.
Application:
For hand used nut driver sockets.
7201
Connecting device with retaining ring, style G 6.3 + G 10 + G 12.5.
Suitable for:
DIN 3126, ISO 1173, style D 6.3 and D 8.
Drive:
DIN 3121, ISO 1174, style G 6.3 + G 10 + G 12.5.
Application:
Suitable for bits C 6.3 and C 8.
24637
Power bit holder.
Material:
High-quality chrome-molybdenum steel, through-hardened,
chrome-plated and polished.
Drive:
DIN 3126.
Application:
For use of C 6.3 bits.
7230
Tool shaft, style A 5.5.
Standards:
Adapter DIN 7428.
Suitable for:
DIN 3121, ISO 1174, style F 6.3.
Drive:
DIN 3126, ISO 1173, style A 5.5.
Application:
For machine used nut driver sockets.
7240
Tool shaft, style E 6.3.
Standards:
Adapter DIN 7428.
Suitable for:
DIN 3121, ISO 1174, style F 6.3 and F 10.
Drive:
DIN 3126, ISO 1173, style E 6.3.
Packaging:
Plastic box, reusable and dust repellent.
Application:
For machine used nut driver sockets.
Extra:
Easily identifiable content with large symbols.
7280
Tool shaft, style G 7.
Suitable for:
DIN 3121, ISO 1174, style F 6.3.
Drive:
DIN 3126, ISO 1173, style G 7.
Application:
For machine used nut driver sockets.
24636 B5
1/2" hand impact screwdriver set with 5/16" bits and bit holder, 6
pcs.
Material:
High-quality chrome-molybdenum steel, through-hardened,
with hand protection.
Drive:
Square 1/2", also suitable for 5/16" bits with adapter.
Application:
For loosening jammed screws or nuts together
with the Wiha 5/16" impact bits and holder.
Maximum transmissible torque of up to 200 Nm.
Extra:
The insert is hardened and lacquered at the impact end to prevent the
chipping of chrome parts or mushroom-shaped deformations.
Wiha impact screwdriver assortment.
The complete range.
Wiha adapters.
Impact screwdriver and bits.
Order-No.
32561 9
1.6
5/16
32
5
32562
11
1.6
5/16
32
5
32563 14
2.0
5/16
32
5
Order-No.
32558 PH2
5/16
32
5
32559
PH3
5/16
32
5
32560 PH4
5/16
32
5
Order-No.
32564 T30
5/16
32
5
32565
T40
5/16
32
5
32566 T45
5/16
32
5
32567
T50
5/16
32
5
Impact screwdriver and bits.
Order-No.
32556 1/2
163
1
Order-No.
32547 5/16
1/2
38
1
Order-No.
Series
32573 24636
B5
1
24636
1/2" Hand impact screwdriver
7050
9x1
.
6
11x1
.
6
7051
PH2x5/16 PH3x5/16
7204Z-516 Bit holder
For nut driver inserts and bits
Order-No.
01933 1/4
1/4
25
5
04204
3/8
1/4
30
5
Order-No.
01924 1/4
1/4
25 D 6.3
2
01926
1/4
3/8
30 D 6.3
2
01922 1/4
1/2
35 D 6.3
2
01927
5/16
3/8
30
D 8
2
01923 5/16
1/2
35
D 8
2
Order-No.
33230 1/4
1/4
22
1
For machine used nut driver sockets.
Order-No.
01934 1/4
5.5
50
5
Order-No.
04685 1/4
1/4
100
5
01935
1/4
1/4
50
5
04684 3/8
1/4
100
5
04362
3/8
1/4
50
5
Order-No.
01936 1/4
7
75
5
