Page 61: Wiha info
Wiha
Info
Wiha ErgoStar
The right idea:
a flowing movement means all L-keys
are ready for removal.
121
www.wiha.com
369T
Ball end hex L-key, long.
Blade:
Chrome-vanadium steel, through hardened, chrome-plated.
Standards:
Based on ISO 2936L.
Application:
Specially for hard-to-reach screws and confined spaces.
Extra:
Increase in the hand working space of over 30%
and thus a reduction of risk of injury to the knuckles
and fingertips thanks to 95° bend of the L-key.
Improved access through a reduction of the L-key head
height of up to 15%.
The ball end enables the user to work at angles up to 25°.
369F
Ball end hex L-key, long.
Blade:
Chrome vanadium steel, through-hardened, colour-coded.
Standards:
Based on ISO 2936L.
Application:
Especially for screws that are difficult to access.
Extra:
The ball end enables the user to work at angles up to 25°.
Colour coding for immediate identification of L-keys.
120
369R Zoll
Ball end hex L-key, long.
With MagicRing
®
. Inch sizes.
Blade:
Chrome-vanadium steel, through hardened, chrome-plated.
Standards:
Based on ASME B18.3.
Application:
Insert hex inch screws into and remove from boreholes,
especially in difficult to access areas.
Extra:
MagicRing
®
made from spring steel holds all standard screws
tight at various angles (available from 1/8").
The ball end enables the user to work at angles up to 25°.
95°
–60%
For Allen screws (metric).
Order-No.
35482 1.5
91
5.5
10
35483
2
101
9
10
35484 2.5
113
9.5
10
35485
3
128
11
10
35486 4
142
13
10
35487
5
163
15
10
35488 6
184
18
10
35489
8
206
22
10
35490 10
231
28
5
369T S9
Ball end hex L-key set in ProStar.
Chrome-plated, 9 pcs.
Blade:
Chrome-vanadium steel, through hardened, chrome-plated.
Standards:
Based on ISO 2936L.
Application:
Specially for hard-to-reach screws and confined spaces.
Extra:
Space saving ProStar allows the easy removal of each key
without moving any others.
Increase in the hand working space of over 30%
and thus a reduction of risk of injury to the knuckles
and fingertips thanks to 95° bend of the L-key.
Improved access through a reduction of the L-key head
height of up to 15%.
The ball end enables the user to work at angles up to 25°.
Order-No.
35480
369T S9
5
369T
1.5
2
2.5
3
4
5
6
8
10
For Allen screws (metric).
Order-No.
34269 1.5
91
15
black
10
34270
2
101
18
green
10
34271 2.5
113
20
turquoise
10
34272
3
128
23
light blue
10
34273 4
142
29
purple
10
34274
5
163
33
red
10
34275 6
184
38
orange
10
34276
8
206
44
yellow
10
34277 10
231
50
grey
5
369 H9F
Hexagon ball end L-key set in Classic holder.
Blade:
Chrome vanadium steel, through-hardened, colour-coded.
Standards:
Based on ISO 2936L.
Application:
Especially for screws that are difficult to access.
Extra:
Popular key sizes kept in a well-organised holder.
Simple, rapid operation with solid stopping point for L-keys.
The ball end enables the user to work at angles up to 25°.
Colour coding for immediate identification of L-keys.
Order-No.
34268
369 H9F
5
369F
1.5
2
2.5
3
4
5
6
8
10
SB 369 H9F
Hexagon ball end L-key set in Classic holder.
In blister pack.
Order-No.
35683
SB 369 H9F
Wiha hexagon L-key (metric).
For Allen screws (inch).
Order-No.
29471 0.05
72
13
1.27
10
29472
1/16
80
15
1.59
10
29474 5/64
88
18
1.98
10
29473
3/32
101
20
2.38
10
29475 7/64
111
21
2.78
10
24302
1/8
121
23
3.17
10
24304 9/64
136
27
3.57
10
24303
5/32
148
29
3.96
10
24305 3/16
163
33
4.76
10
24306
7/32
176
36
5.55
10
24307 1/4
191
38
6.35
10
24308
5/16
210
43
7.93
10
24341 3/8
232
50
9.52
10
For Allen screws (inch).
369R HZ13
Hexagon ball end L-key set in ErgoStar holder.
From size 1/8" with MagicRing, chrome-plated, 13 pc. inch design.
Blade:
Chrome-vanadium steel, through hardened, chrome-plated.
Standards:
Based on ASME B18.3.
Application:
Insert hex inch screws into and remove from boreholes,
especially in difficult to access areas.
Extra:
Mechanical operation of the space-saving ErgoStar holder
makes simplest removal of each individual L-key possible
without movement of the others.
MagicRing
®
made from spring steel holds all standard screws
tight at various angles (available from 1/8").
The ball end enables the user to work at angles up to 25°.
Order-No.
36521
369R HZ13
5
369 Zoll C
0.05
1/16
5/64
3/32
7/64
369R Zoll
1/8
9/64
5/32
3/16
7/32
1/4
5/16
3/8
SB 369R HZ13
Hexagon ball end L-key set in ErgoStar holder.
From size 1/8" with MagicRing, chrome-plated, 13 pc. inch design.
In blister pack.
Order-No.
36522
SB 369R HZ13
5
369R SZ13
Ball end hex L-key set in ProStar.
With MagicRing
®
, chrome-plated, 13 pcs. Inch sizes.
Blade:
Chrome-vanadium steel, through hardened, chrome-plated.
Standards:
Based on ASME B18.3.
Application:
Insert hex inch screws into and remove from boreholes,
especially in difficult to access areas.
Extra:
Space saving ProStar allows the easy removal of each key
without moving any others.
MagicRing
®
made from spring steel holds all standard screws
tight at various angles (available from 1/8").
The ball end enables the user to work at angles up to 25°.
Order-No.
24190
369R SZ13
5
369 Zoll C
0.05
1/16
5/64
3/32
7/64
369R Zoll
1/8
9/64
5/32
3/16
7/32
1/4
5/16
3/8
Wiha MagicRing
®
hexagon L-key.
Securely holds hexagon bolts in place in any position.
N E W
N E W
N E W
N E W
N E W
Order-No.
35481
SB 369T S9
5
SB 369T S9
Ball end hex L-key set in ProStar.
Chrome-plated, 9 pcs.
Blister packed.
N E W
SB 369R SZ13
Ball end hex L-key set in ProStar.
With MagicRing
®
, chrome-plated, 13 pcs. Inch sizes.
Blister packed.
Order-No.
24850
SB 369R SZ13
5
MagicRing
®
MagicRing
®
MagicRing
®
MagicRing
®
MagicRing
®
MagicRing
®
MagicRing
®
MagicRing
®
95°
–60%
