193
www.wiha.com
7244 Power nut driver insert, hex - style E 6.3.
Material: High-quality chrome vanadium alloy steel, through-hardened,
phosphate coated surface.
Drive: DIN 3126, ISO 1173, style E 6.3.
Application: For mechanical fastening and unfastening.
Extra: Rounded hex opening in the corners for protection of the screw heads.
7244M Power nut driver insert, hex with magnet - style E 6.3.
Material: High-quality chrome vanadium alloy steel, through-hardened,
phosphate coated surface.
Drive: DIN 3126, ISO 1173, style E 6.3.
Application: For mechanical fastening and unfastening.
Extra: With a powerful permanent magnet embedded in brass.
Rounded hex opening in the corners for protection of the screw heads.
7204 Power hex nut driver, 1/4" drive.
Material: High-quality chrome-molybdenum steel, through-hardened,
phosphate coated surface.
Drive: DIN 3129, ISO 2725-2.
Application: For tightening and loosening hex screws with electric or pnewmatic
screwdrivers (rotary or impact screwdrivers).
Extra: Rounded hex opening in the corners for protection of the screw heads.
7204M Power hex nut driver with magnet, 1/4" drive.
Material: High-quality chrome-molybdenum steel, through-hardened,
phosphate coated surface.
Drive: DIN 3129, ISO 2725-2.
Application: Mainly for fastening and unfastening in self-tapping sheet metal screws
with electric or pnewmatic screwdrivers (rotary or impact screwdrivers).
The magnet simplifies the guidance of the screws while fastening.
Extra: With a powerful permanent magnet embedded in brass.
With 0.03 mm raised cladding in comparison to the standard
model for a considerably increased service life.
Due to the rounded hex opening, flat screws can easily be gripped.
7205 Power TORX ® nut driver insert, 1/4" drive.
Material: High-quality chrome-molybdenum steel, through-hardened,
phosphate coated surface.
Drive: DIN 3129.
Application: For external TORX ® screws and self-tapping screws with TORX ® head.
Suitable for electric or pnewmatic screwdrivers
(rotary or impact screwdrivers).
192
Wiha power nut driver product line.
The entire line for hand and machine use.
Wiha power nut driver
product line.
• Extensive application
possibilities and large range
of tools for electric and
pnewmatic screwdrivers
as well as hand-operated
nut driver inserts
• Nut driver inserts (1/4" drive)
in high-quality special chrome
vanadium steel; also available
with incorporated permanent
magnet that safely guides the
screws when installing
• Hand impact screwdriver with
hardened, lacquered impact
end against chipping of chrome
parts or mushroom-shaped
deformations
The jack-of-all-trades product line is
rounded off with universal
connection pieces, parts and
smooth-running ratchets.
With a universal joint (connection
pieces) and a locking button
(ratchets) for holding or quickly
releasing the attached tools, they're
excellently equipped for working in
hard-to-reach places. The 3-compo-
nent handle (SoftFinish
® ) of the
ratchets also guarantees comfort-
able, safe use.
Whether tools or accessories,
whether its hand or machine-
operated nut drivers: With this
versatile assortment the user is
also equipped for difficult and
special cases.
For those who place high demands
in their tools: the extensive Wiha
nut driver product line for hand
and machine operation will
definitely satisfy.
The high quality power nut driver
inserts for example stand up to
especially heavy loading.
Another advantage is their hexagon
opening with rounded corners:
It grasps even flat bolts easily and
extremely gently. With the incorpo-
rated permanent magnet and
optional bit holder, particular
attention was also paid to practical,
user-friendly details.
A remedy for tough cases: The new
hand impact screwdriver with hand
protection and a changeover
function is a specialist for jammed
bolts and nuts. The matching 5/16"
bits for PH, slotted and TORX
® drives
are produced of special chrome
vanadium steel and through-hard-
ened, making them especially
impact and break-resistant.
Machine-operated nut driver inserts.
Order-No.
32513 5.5
9 50 5
32514 7 11 50 5
32515 8 12 50 5
32516 10 14 50 5
32517 12 17 50 5
32518 13 18 50 5
32519 1/4 10 50 5
Order-No.
32520 5.5
9 50 5
32521 6 10 50 5
32522 7 11 50 5
32523 8 12 50 5
32524 10 14 50 5
32525 12 17 50 5
32526 13 18 50 5
32528 1/4 10 50 5
32530 5/16 12 50 5
32529 3/8 14 50 5
32527 1/2 17 50 5
Machine-operated nut driver inserts.
Order-No.
32531 5.5
9.4 13 23 1
32532 6 10.0 13 23 1
32533 7 11.3 13 23 1
32534 8 12.5 13 23 1
32535 10 15.0 13 23 1
32536 12 17.5 13 23 1
32537 13 18.8 13 23 1
32538 1/4 10.0 13 23 1
32539 5/16 12.5 13 23 1
32540 3/8 15.0 13 23 1
Order-No.
32541 7
11.6 13 23 1
32542 8 12.8 13 25 1
32543 10 15.3 13 28 1
32544 13 19.1 13 30 1
32545 1/4 10.3 13 23 1
Order-No.
32550 E6
8.7 13 23 1
32551 E8 9.2 13 23 1
32552 E10 12.2 13 23 1
