Wiha Tools Product Catalogue 2012-2014 - Manual (Page 41)

N E W
N E W
81
www.wiha.com
2850 TorqueFix ® torque screwdriver.
With a fixed torque value pre-set by Wiha.
Automatic release.
Handle: Ergonomic multi-component handle, particulary light and compact.
Handle sizes proportioned to optimise torque setting.
Audible and perceptible click when the pre-set torque has been attained.
Standards: EN ISO 6798, BS EN 26789, ASME B107.14M.
Accuracy: ±6%, traceable to national standards.
Application: For applications where recommended torque settings are important.
Use in combination with a Wiha torque interchangeable blade.
Extra: Delivered in practical plastic box, incl. factory calibration certificate.
Note: The below articles are available from stock.
Further articles with pre-set, customer torque values
of between 0.15 and 8 Nm are available on request.
2850 S2 Torque cable key for circular plug connectors.
For Wiha torque screwdrivers.
Handle: TorqueFix ® torque screwdrivers.
Ergonomic multi-component handle, particulary light and compact.
Material: Robust, glass-fibre reinforced plastic combines the high quality hexagonal
stainless steel insert with the blade tang of chrome-vanadium-
molybdenum steel.
Application: For controlled fastening of circular plug connectors with hexagonal head
according to specified torque.
292 easyTorque torque screwdriver.
With a fixed torque value ex-factory.
Handle: Multi-component handle optimally designed for the hand
enables optimal power transmission.
Audible and perceptible click when the pre-set torque has been attained.
Rapid identification with imprint on handle end.
Unlimited loosening torque.
Mechanism insensitive to industrial lubricants.
Accuracy: ±10%
Application: For applications where recommended torque settings are important.
Use in combination with a Wiha torque interchangeable blade.
80
2852 TorqueVario ® -S Torque screwdriver.
Torque value can be set via window scale.
Automatic release.
Handle: Torque infinitely adjustable with Torque-Setter setting tool (also supplied).
Ergonomic multi-component handle, particulary light and compact.
Handle sizes proportioned to optimise torque setting.
Audible and perceptible click when the pre-set torque has been attained.
Standards: EN ISO 6798, BS EN 26789, ASME B107.14M.
Accuracy: ±6%, tracing to national standards (see table for other tolerances).
Application: For applications where recommended torque settings are important.
Use in combination with a Wiha torque interchangeable blade.
Extra: Delivered in practical plastic box, incl. factory calibration certificate.
285-900 Torque-Setter.
Setting tool for variable torque screwdrivers.
Included in every torque screwdriver delivery.
Blade: Octagonal blade, through hardened, zinc-plated.
Handle: Cellulose acetate with micro-fine surface structure.
Supplement: Included in every torque screwdriver delivery.
2852 S10 TorqueVario ® -S Torque screwdriver set, 13 pcs.
Torque value can be set via window scale.
With bit universal holder and 10 Phillips / Pozidriv / TORX
® /
hex Standard bits.
Handle: Model 1.0-5.0 Nm.
Torque infinitely adjustable with Torque-Setter setting tool (also supplied).
Ergonomic multi-component handle, particulary light and compact.
Audible and perceptible click when the pre-set torque has been attained.
Standards: EN ISO 6798, BS EN 26789, ASME B107.14M.
Accuracy: ±6%, traceable to national standards.
Application: For applications where recommended torque settings are important.
Extra: Delivered in robust metal box, incl. factory calibration certificate.
2852 S10-01 TorqueVario ® -S Torque screwdriver set, 13 pcs.
Torque value can be set via window scale.
With bit universal holder and 10 TORX
® / TORX PLUS ® Standard bits
especially for applications with indexable cutter inserts.
TorqueFix ® and Torque cable key.
Order-No.
26925
0.4 6% 4 112 23 1
26127 0.5 6% 4 112 23 1
26047 0.6 6% 4 112 23 1
26327 0.8 6% 4 112 23 1
26048 0.9 6% 4 112 23 1
26133 1.1 6% 4 119 30 1
26049 1.2 6% 4 119 30 1
26901 1.5 6% 4 119 30 1
26051 2.0 6% 4 119 30 1
26128 2.5 6% 4 119 30 1
26052 3.0 6% 4 126 36 1
26129 3.8 6% 4 126 36 1
26053 5.0 6% 4 132 41 1
26130 5.5 6% 4 132 41 1
34533 6.0 6% 4 132 41 1
26131 7.2 6% 4 132 41 1
Order-No.
36846 0.4
9 230 78 112 23 1
36847 0.6 13 230 78 112 23 1
36848 1.5 22 240 90 119 30 1
easyTorque.
Order-No.
36229 0.5
10% 4 130 34 1
36230 0.6 10% 4 130 34 1
36240 0.9 10% 4 130 34 1
36231 1.1 10% 4 130 34 1
36233 1.2 10% 4 130 34 1
36234 2.0 10% 4 130 34 1
36235 2.0 10% 4 130 34 1
36236 2.5 10% 4 130 34 1
36237 3.0 10% 4 130 34 1
36238 3.8 10% 4 130 34 1
36320 4.0 10% 4 130 34 1
36321 4 . 5 10% 4 130 34 1
36239 5.0 10% 4 130 34 1
TorqueVario ® -S with scale.
Order-No.
36849 0.04-0.46
•10% 4 127 23 1
26888 0.1-0.6 10% 4 127 23 1
36850 0.1-0.6 6% 4 127 23 1
26461 0.4-1.0 6% 4 127 23 1
26462 0.8-2.0 6% 4 131 30 1
26463 1.0-5.0 6% 4 138 36 1
26464 2.0-8.0 6% 4 142 41 1
• Accuracy ±10% in the range from 0.1- 0.46 Nm
Order-No.
26864 150
80 1
TorqueVario ® -S sets.
Order-No. Series
26893 2852 S10 1
2852 TorqueVario ® -S Torque screwdriver ,
Modell 1,0-5,0 Nm
2859 Torque bit universal holder
285-900 Torque-Setter.
7011 Z PH1x25 PH2x25
7012 Z PZ1x25 PZ2x25
7015 Z T10x25 T15x25 T20x25 T25x25
7013 Z 3.0x25 4.0x25
Order-No. Series
34614 2852 S10-01 1
2852 TorqueVario ® -S Torque screwdriver,
Modell 1,0-5,0 Nm
2859 Torque bit universal holder
285-900 Torque-Setter.
7015 Z T7x25 T8x25 T9x25 T10x25 T15x25
7016 Z 7IPx25 8IPx25 9IPx25 10IPx25 15IPx25
Wiha torque screwdrivers.
N E W
N E W N E W
N E W
with scale
with scale
with scale
