Velleman projects K4040 Assembly instructions User Manual
Page 5
5
Construction
C1 :
47nF
(473)
1. Ceramic Capacitor
C ...
Assembly of the small input PCB P4040i:
This PCB is used to connect the input signal (via two RCA sockets) via two holes at the rear of the
cabinet.
SK1 : CINCH
SK2 : CINCH
2. CINCH / RCA connector
L
GND
R
GND
3. Shielded wire connector
LEFT
RIGHT
GND
GND
P4040i
15cm
