Construction
LD1
LD2
LD3
LD4
LD5
LD6
LD7
7. LEDs. Watch the polarity!
LD1
CATHODE
3mm RED
SK1 : 10 POLE
SK2 : 10 POLE
SK3 : 10 POLE
SK4 : 10 POLE
SK5 : 10 POLE
SK...
HOT GLUE GUN
LIJMPISTOOL
PISTOLET A COLLE
HEISKLEBEPISTOLE
SK6 to SK10 : 2P+2P+2P+2P+2P
SK11 to SK13 : 2P+2P+2P
SK14: 2-POLE (wide)
SK15: 2-POLE (wide)
SK16: 2-POLE (wide)
SK17: 2-POLE (wide)
SK18: 2-POLE (wide)
SK19: 2-POLE (wide)
SK20: 2-POLE (wide)
9. PC Terminal blocks (Slide the
terminal blocks, one into each other)
8. PCB Edge Connectors
(Watch the orientation!)
