2
Features:
Works together with K6710, K8049, K8051, K8055, K8056, K6714 -(16), K2633, …
15 open collector contacts : Max. 50V/50mA.
LED indication for each output.
Multiple sensors possible.
Transmitter - Receiver range : up to 20m
4 different modes :
• 15 independent outputs.
• 15 rotary outputs
• 7 independent outputs & 8 rotary outputs.
• 7 rotary outputs & 8 rotary outputs (independent from each other).
3 addressed allow the use of multiple receivers in one room.
Optional board-to-wire connectors-female (BTWF5 & BTWF20)
Optional IR-receivers (IR38DM)
Specifications:
Power supply : 8 –14VDC or 2x6 to 2x12VAC (150mA).
Current consumption : all outputs off : 10mA
all outputs on : 150mA
Features & Specifications
