8

11. Insert the IC’s in the socket

(Check the position of the notch)

IC...

PIN 1

1

q IC1: 741
q IC2: LM3916

Mount the units in a suitable housing or on a suitable panel:

12. Mounting possibility:

A. Make or search for suitable bracket:
