10
C. Mount the PCB’s with spacers onto the bracket:
15mm SPACER
2...3mm FRONTPANEL
PCB
40mm M3 BOLT
40mm M3 BOLT
BRACKET
BRACKET
15mm SPACER
FRONTPANEL
PCB
M3 NUT
LOCK WASHER
SOLDER
SIDE
15mm SPACER
15mm SPACER
M3 NUT
LOCK WASHER
