- UK -

p. 5

USB PIC PROGRAMMER AND TUTOR BOARD

• Follow this link to Velleman support: http://www.velleman.eu/support/
• Click on “Downloads per product (drivers, manuals, software, ...)”.
• Enter Product code: EDU10 and then click Search button.
• Download and extract the demos for EDU10.

Download and extract PICkit 2 V2.61

• In the folder “PICkit 2 v2.61 run setup.exe”. This will install the program PICkit 2 v2.61 with the .NET framework.
• When installation is complete, you can connect the EDU10 to the computer’s USB port.
• Double click the “PICkit 2 v2.61” icon on the desktop.
• The “PICkit 2 Programmer - EDU10” should show text:

“PICkit 2 connected ID = EDU10
PIC Device Found”

Download software package with demos
