Fastener torque specifications – Spicer Convertible Tandem Axles User Manual
Page 71
65
Fastener T
orque
Specifications
Fastener Torque Specifications
Fastener Torque Specifications
Location
Size
Lb-Ft.
N•m
WHEEL DIFFERENTIAL AND GEARING
Front Pinion Helical Nut
M48 x 1.5
900 + 100
1220 + 135
Output Shaft Nut
M42 x 1.5
900 + 100
1220 + 135
Rear Pinion Nut
M48 x 1.5
900 + 100
1220 + 135
Ring Gear, Diff. Case Bolts
M20 x 1.5 x 55
500 + 25
675 + 30
CARRIER
Carrier Diff. Bearing Cap
M18 x 1.5 x 85
265 + 15
360 + 20
Carrier to Housing Cap Screws
M16 x 1.5 x 85
250 + 15
335 + 20
M16 x 1.5 x 55
250 + 15
335 + 20
Carrier to Housing Nuts
M16 x 1.5
250 + 15
335 + 20
Pilot Bearing Web
M16 x 1.5 x 70
210 + 10
285 + 15
Differential Lock Switch
M14 x 1.5
10 + 1
15 + 3
Differential Lock End Cap
2.375 - 16 UN-2A
65 + 10
85 + 15
HOUSING
Rear Cover Caps Screws
M16 x 1.5 x 70
250 + 15
335 + 20
M16 x 1.5 x 55
250 + 15
335 + 20
Rear Cover Nuts
M16 x 1.5
250 + 15
335 + 20
Magnetic Plug (Fill)
1 x 11.5 NPTF
50 + 5
72 + 5
Drain Plug
0.750 - 14 NPTF
50 + 5
72 + 5
Housing Breather
0.375 - 18 NPTF
20 - 26
27 - 35
Temperature Sending Plug
0.500 - 20 NPTF
50 + 5
72 + 5
Axle Shaft to Wheel Hub Nut
0.625 - 18
180 + 10
245 + 15
0.750 - 16
315 + 30
425 + 40
Wheel Diff. Lock Caps
2.37 - 16UN-2A
65 + 10
85 + 15
