Glossary and Nomenclature
14
G
los
sa
ry
and
N
om
e
nc
latu
re
Rear Drive Axle Nomenclature
R-head carrier
or rear carrier
Inner pinion
bearing cone
Pinion
cage shim
Inner pinion
bearing cup
Pinion bearing
spacer
Pinion
pilot bushing
Pinion
Pinion
cage
Outer pinion
bearing cup
Outer pinion
bearing cone
Pinion
seal
Pinion
yoke
Pinion
nut
Thrust
bolt
Thrust bolt
jam nut
Side gear
thrust washer
Carrier
cap bolt
Side gear
Side
gear
Plain half
diff case
Wheel diff
spider
Side pinion
thrust
washer
Plain half
inner cone
Plain half
inner cup
Side
pinion
Plain half
carrier cap
Plain half
bearing
adjuster
Side gear
thrust
washer
Flange half
bearing
adjuster
Flange half
bearing
cone
Flange half
bearing cup
Flange half
diff case
Ring
gear
Flange half
carrier cap
