Front drive axle nomenclature, Glossary and nomenclature – Spicer Drive Axles Failure Analysis Service Manual User Manual
Page 13
Glossary and Nomenclature
12
G
los
sa
ry
and
N
om
e
nc
latu
re
Front Drive Axle Nomenclature
Wheel diff
spider
Side Gear
Side gear
thrust washer
Flange half
diff case
Ring
gear
Side pinion
thrust washer
Flange
Half
Bearing
Cone
Flange half
bearing
adjuster
Flange half
bearing cup
Plain half
carrier cap
Carrier
cap bolt
Side
pinion
D-head carrier
or front carrier
Side
gear
Side Gear
thrust washer
Plain half
diff case
Plain half
bearing cone
Pinion
pilot bearing
Inner pinion
bearing cone
Inner pinion
bearing cup
Pinion
cage
Outer pinion
bearing cone
Pinion
nut
Pinion
Pinion
bearing spacer
Pinion
cage shim
Outer pinion
bearing cup
Helical
gear
Pinion
roll pin
Plain half
bearing cup
Thrust bolt
Plain half
bearing adjuster
Flange half
carrier cap
Jam nut
