1
Introduction
Introduction
Introduction
Dana Commercial Vehicle Division, presents this publication to aid in maintenance and overhaul of Spicer single drive axles.
Instructions contained cover the models listed. Their design is common, with differences in load capacity. Capacity variations
are achieved by combining basic differential carrier assemblies with different axle housings, axle shafts and wheel equipment.
Model Listing
Model Information
Rear Axle Load Capacity
S10-110 10,000
S12-110 12,000
S14-110 14,000
S16-130 16,000
S 14 - 1 1 0 L
S - S i n g l e R e a r A x l e
O p t i o n s
B - B u s S p e c i f i c
D - D i f f e r e n t i a l L o c k
H - H e a v y W a l l
I - I n t e g r a l B r a k e
L - L i m i t e d - S l i p
R - R e t a r d e r / P a r k i n g B r a k e R e a d y
W - W i d e - t r a c k
F - R o l l O v e r
G e a r T y p e
1 - S t a n d a r d S i n g l e R e d u c t i o n
2 - D u a l R a n g e
3 - P l a n e t a r y D o u b l e R e d u c t i o n
4 - C o n t r o l l e d T r a c t i o n D i f f e r e n t i a l
5 - H e l i c a l R e d u c t i o n
D e s i g n L e v e l
H e a d A s s e m b l y S e r i e s
G A W R a t i n g x 1 0 0 0 l b s .
