65
Service Procedures
Hose and Supply Tank Selection Chart
The following hose lengths and sizes are necessary
for correct TPCS operation.
Any deviations may cause the system to function incorrectly
and may reduce the ability to detect low tires.
Front Channel Plumbing Requirements
Rear Channel Plumbing Requirements
CAUTION
Min. Tank Size Main Run Jounce
Standard Front (1 Axle) 1400 in3 18' to 20' 5/8" OD 6' to 8' per axle 5/16" ID Only
(6 gal.) 21' to 23' 13/32" ID 6' to 8' per axle 5/16" ID Only
25' to 27' 1/2" OD 6' to 8' per axle 5/16" ID Only
Dual Front (2 Axle) Both Non-Driven 1400 in3 18' to 21' 5/8" OD 6' to 8' per axle 5/16" ID Only
(6 gal.) 21' to 25' 13/32" ID 6' to 8' per axle 5/16" ID Only
25' to 29' 1/2" OD 6' to 8' per axle 5/16" ID Only
Dual Front (2 Axle) 1 Driven, 1 Non-Driven 2800 in3 18' to 21' 5/8" OD 6' to 8' per axle 5/16" ID Only
(12 gal.) 21' to 25' 13/32" ID 6' to 8' per axle 5/16" ID Only
25' to 29' 1/2" OD 6' to 8' per axle 5/16" ID Only
Min. Tank Size Main Run Jounce
Single Rear (1 Axle) 1400 in3 15' to 17' 5/8" OD 7' to 9' per axle 5/16" ID Only
(6 gal.) 18' to 20' 13/32" ID 7' to 9' per axle 5/16" ID Only
21' to 24' 1/2" OD 7' to 9' per axle 5/16" ID Only
Tandem Rear (2 Axle) 1400 in3 14' to 17' 5/8" OD 7' to 9' per axle 5/16" ID Only
(6 gal.) 16' to 20' 13/32" ID 7' to 9' per axle 5/16" ID Only
18' to 24' 1/2" OD 7' to 9' per axle 5/16" ID Only
Tridem Rear (3 Axle) 2800 in3 16' to 20' 13/32" ID 5' to 7' per axle 5/16" ID Only
(12 gal.) 18' to 24' 1/2" OD 5' to 7' per axle 5/16" ID Only
